• Model NO.：NCF-TC
• Temperature：750±5ºC
• Quantity of Thermocouple：3 PCS,American Omega
• Working Mode：Automatically Controlled by PC
• Air Cover：Φ75 mm × 500 mm
• Color：White
• Test Object：Building Material
• Heating Furnace Size：Φ95 mm × Φ75 mm × 150 mm
• Language：English
• OEM Service：Available
• Function：Testing The Combustion Performance Classification
• Transport Package：Plywood Case
• Specification：Stainless steel
• Trademark：AI
• Origin：China
• HS Code：9031809090
• Production Capacity：30 Sets,Month

Basic Info.

Model NO. NCF-TC Temperature 750±5ºC Quantity of Thermocouple 3 PCS,American Omega Working Mode Automatically Controlled by PC Air Cover Φ75 mm × 500 mm Color White Test Object Building Material Heating Furnace Size Φ95 mm × Φ75 mm × 150 mm Language English OEM Service Available Function Testing The Combustion Performance Classification Transport Package Plywood Case Specification Stainless steel Trademark AI Origin China HS Code 9031809090 Production Capacity 30 Sets/Month

Product Description

Introduction:

The non-combustibility test device is developed according to ISO 1182 and GB/T 5464 building materials non-combustibility test method. It is mainly used in the non-combustibility test method of building materials and is suitable for testing the combustion performance classification of Class A fireproof materials in the GB8624 combustion performance classification of building materials.
The non-combustibility tester can be applied to composite products, and can also be used to test each component material of the product. The non-combustibility tester also complies to BS 476-4 & 11 and IMO FTP Part 1 standards, which are used in the UK Fire test for building materials, railway locomotive materials, and ship non-metallic products.

Standard:
• EN ISO 1182:2021:Reaction to fire tests for products - Non-combustibility test;
• IMO FTPC Part 1:Non-combustibility test;
• BS 476-4:Fire Test to Building Material -Standard Method BS 476-4 Fire tests on building materials and structures- Part 4: Non-combustibility test for materials;

Feature

1, Applicable standards:ISO 1182 2020,BS 476-4 & 11,ASTM E 136;
2, Intelligent test system with Patent design;
3, Stainless steel burner, beautiful and easy to clean;
4, The heating furnace size: Φ95 mm × Φ75 mm × 150 mm;
5, 3 mm × 0.2 m Ni 80% Cr 20% resistance band;
6, Air cover: Φ75 mm × 500 mm;
7,Thermocouple:insulated nickel-chromium-nickel-aluminum Φ1.5 mm
8, The non-combustibility test device is equipped with the power controller;
9, The temperature balanced time at 750ºC is about 35min~40min;
10, Thermometers range: 0 ~ 1000 ºC ± 5%;
11, The non-combustibility test device is equipped with mirror to see the internal of the furnace.

Control system
1, High degree of automation, test procedure safe and reliable, easy to operate;
2, The non-combustibility test device uses high-quality strip heater, furnace temperature was raised to 900 ºC;
3, PLC control system + SSR temperature control system extending
the life of furnace:
4, PLC output signal to control the heating voltage 0-110VAC. Eliminate the influence of voltage fluctuation on temperature.
5, Temperature control: 750ºC±2ºC;Resolution:0.1ºC;
6, The sample is move up-down into the furnace automatically by motor.
7, Computer controlled with Labview based software.
8, The non-combustibility test device has an audible alarm and alarm display functions accidents.
9, Two furnace thermal couple for furnace control and temperature record, location show in below figure, compliance with ISO 1182-2020,
10, Thermocouple with copper cylinder for furnace temperature calibration.
11. Furnace temperature calibration and wall temperature calibration
12.Standard and new furnace heating mode.


Installation requirements
1.Power:220V, 50Hz, 1500W ;
2.Weight:50kg;
3.Dimensions: 500mm x 500mm x 1500mm

Factory overview

Customer Feedback

Germany

USA

Transporation

FAQ
1.What's the delivery time?
About 50 days.

2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.

3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.

4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every person.
