Cod Reactor and Test Tube Chemical Test Heater 25 Positions
Shanghai Lianhua Industrial Co., Ltd.- After-sales Service：on-Line Support
- Warranty：One Year
- Application：Laboratory Heating Sample
- Detect Time：1-999 Minutes
- Measurement Range：45-190 Degree
- Accuracy：1%
Base Info
- Model NO.：LH-25A
- Number of Cuvettes：25 Vials X 16 mm (Single Block)
- Name：Reactor
- Transport Package：Express, Carton
- Specification：340x240x220mm
- Trademark：Lianhua or no logo
- Origin：China
- HS Code：9031809090
- Production Capacity：50000 Units , Year
Description
1 >Product Introduction
LH-25A intelligent multi-parameter reactor adopts high-definition touch screen, high polymer engineering plastic shell, streamlined appearance design. Stored 6 digestion procedures and 3 custom digestion procedures, the technical indicators fully meet or In line with or above national standards.
Providing a digital timer with automatic switch-off feature and audible signal to alert technicians.
2 >Functional characteristics
(01) By heating samples from ambient to 150° C in less than 10 minutes.
(02) Built-in 3 kinds of digestion program (COD, total nitrogen, total phosphorus) and 1 sets of custom digestion procedures.
(03) The temperature and timing can be adjusted freely in a large range.
(04) Providing a digital timer with automatic switch-off feature and audible signal to alert technicians.
(05) With transparent protective cover.
(06) User can distinguish water samples by the digital number of the holes.
(07) Large screen LCD display.
3 >Technical Parameters
| Instrument name | Intelligent multi-parameter reactor |
| Product model | LH-25A |
| Sample positons | 25 |
| Display mode | LCD |
| Stored program | COD, total phosphorus, total nitrogen |
| Time switch | 3 |
| Heating rate | Rises to 165 degrees in 10 minutes |
| Temperature indication error | ≤± 2ºC |
| Temperature field uniformity | ≤± 2ºC |
| Digestion temperature | 45~190ºC(Users can set their own) |
| Timing range | 1 minutes to 96 hours |
| Timing precision | 0.2s/h |
| Time delay protection | √ |
| Batch throughput | 25 |
| Digestion capacity | (0-10)ml |
| Program upgrade | √ |
| Alarm prompt | √ |
| Over temperature alarm | √ |
| Instrument overheat protection | √ |
| Digestion protective plate | Prevent scald of misoperation |
| Digestion protective cover | Integrated safety protection |
| Acid proof shell | Corrosion resistance |
| Rated voltage | AC220V/50Hz |
| Ambient temperature | (5-40)ºC |
| Ambient humidity | relative humidity < 85% (without condensation) |
| Rated Powe | 900W |
| ment Size | 340mm×240mm×214mm |
| Instrument weight | 6.2kg |
| Use | It can be used for digestion of COD, total phosphorus,total nitrogen and so on |
