• Model NO.：TPO-3143
• Temperature Rising Rate：1ºC,Min±6s
• Measurement Range：20~ 93ºC±0.1ºC
• Measurement Accuracy：±1ºC
• Operating Voltage：AC220V, 50Hz
• Operating Power：800W
• Cooling Method：Built-in Air Cooling Fan
• Printer：Thermal Printer, 36 Characters
• Ambient Temperature：5~40ºC
• Dimension：425*430*310mm
• Transport Package：Export Standard Wooden Case
• Specification：390 mm*270 mm*430 mm
• Trademark：TOP
• Origin：Chongqing
• HS Code：9031809090
• Production Capacity：100 Sets,Month

Basic Info.

Model NO. TPO-3143 Temperature Rising Rate 1ºC/Min±6s Measurement Range 20~ 93ºC±0.1ºC Measurement Accuracy ±1ºC Operating Voltage AC220V, 50Hz Operating Power 800W Cooling Method Built-in Air Cooling Fan Printer Thermal Printer, 36 Characters Ambient Temperature 5~40ºC Dimension 425*430*310mm Transport Package Export Standard Wooden Case Specification 390 mm*270 mm*430 mm Trademark TOP Origin Chongqing HS Code 9031809090 Production Capacity 100 Sets/Month

Product Description

Automatic Tag Open-Cup Flash Point Tester TPO-3143

Application
TPO-3143 Automatic Tag Open-Cup Flash Point Tester is designed and manufactured according to Standard ASTM D3143. The instrument applies imported ARM 32-bit embedded SoC system to achieve full automation control.
It is suitable for the determination of flash points by Tag open-cup flash point tester of cutback asphalts having flash points of less than 93ºC.

Feature
High resolution 7 inches LCD color display, touch screen buttons.
English user interface, test procedures fully automatic, intuitive and user-friendly.
Automatic sample cooling & heating, electronic ignition, electronic flame, no gas source required to ensure environment friendly and laboratory safety.
Automatic mechanism movements during and after tests.
It applies high accuracy temperature sensor for temperature measurement .
Once sample reaches preset temperature level, auto ignition and flash point detection start.
It applies UV wavelength flash point detection tube for flash point detection; it features ms response time and high sensitivity.
Air cooling system starts when test ends in order to shorten waiting time.
It features fault self-diagnosis system and reminder functions.
Large memory capacity for 256 test results storage.
It features time, date & week setting functions.
It features temperature limiting function, once temperature reaches threshold, instrument terminates test and raise warning.
Automatic alarm and shutdown functions.
Automatic test results and experiments number saving functions with auto test results printing

Technical parameters:
High resolution 7 inches LCD color display, touch screen buttons
Ignition: electronic ignition, electronic flame, no gas source required
Refrigeration method: Thermo Electric Cooler
Heating method: Electric heating
Temperature rising rate: 1ºC/min±6s
Measurement range: 20~ 93ºC±0.1ºC
Measurement accuracy: ±1ºC
Operating voltage: AC220V, 50Hz
Operating power: 800W
Cooling method: Built-in air cooling fan
Printer: thermal printer, 36 characters,
Ambient temperature: 5~40ºC
Humidity: ≤85%
Dimension: 425*430*310mm
