• Model NO.：UL94-X
• Tube Length：100mm ± 10mm
• Inner Diameter：9.5mm ± 0.3mm
• Flame Height：20mm ± 2mm
• Display：Digital or LCD
• Delivery Time：30 Days
• Test Object：Polymeric Material
• Color：White
• OEM Service：Available
• Transport Package：Plywood Case
• Specification：Stainless steel
• Trademark：AI
• Origin：China
• HS Code：9031809090
• Production Capacity：10 Sets,Month

1Electrical110V AC 60Hz / 230V AC 50Hz2Ambient TemperatureOperating 10°C to 35°C3Gas SuppliesPropane Gas or Methane Gas4Size950 mm (W) x 850 mm (D) x 1350 mm(D)5Weight58KG



Burner and gas control:
2.1, 0°and 45°angle burner convenient adjustment;
2.2, The United States imports Bunsen burner, tube length 100mm ± 10mm, inner diameter of 9.5mm ± 0.3mm; full compliance with the requirements IEC60695-11-4 burner;
2.3, Burner itself can adjust the air and gas flow;
2.4 Japan imported flow meter and flow valve, precise control of the combustion gas flow
2.5, High-precision pressure control valve and pressure gauge
2.6, U-shaped tube differential manometer;
2.7, Precise control of the flame height 20mm ± 2mm;



Control system
3.1, UL94 flame test chamber adopts touch screen for control,testing,calculating and data display.
3.2, Pulsed high voltage electronic automatic ignition.
3.3, PLC automatically records and stores combustion time.
3.5, No need stopwatch and record manuscript; the horizontal and vertical flame test machine can automatically record the test time and generate test reports;
3.6, Ignition time could be set any time. Meet variety of test standards;
3.8 Test level value (HB0 HB40 HB75 / V-0 V-1 V-2) and the standard value on the screen can be checked.
3.9, The horizontal and vertical flame test program on the touch screen can be switched.
3.10, Automatic timer device can record the test of time and stored in the system, the report can be found;
3.11 Test Box is equipped with exhaust fan.

Factory overview

Customer Feedback

Germany

USA

Transporation

FAQ
1.What's the delivery time?
About 30 working days.

2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.

3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.

4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every person.
