Portable Dissolved Oxygen Nitrogen Purity Online Gas Analyzer Price (P950)
BeiJing Cape Golden Gas System Company LTD- After-sales Service：Supplied, Onsite, Online
- Warranty：18 Months
- Brand：Cape-Golden
- Customized：Customized
- Portable：Non Portable
- Certification：CE, ISO9001 13485
Base Info
- Model NO.：P860
- Gas：O2 N2
- Type：Electrochemical Gas Analyzer
- Monitor：Five-Digital Dynamic LED Monitor, Visible Display
- Measure Mode：Air in-Flowing or Convection Diffusing
- Signal Output：4~20mA
- Appearance Dimension：160mm*80mm*176mm (W*H*D)
- Weight：1kg
- Measure Gas Type：Oxygen Nitrogen
- Transport Package：Sea,Air Packing
- Specification：P950
- Trademark：Cape Golden
- Origin：Beijing, China.
- HS Code：9027100090
- Production Capacity：200 Units Per Month
Description
Feature
- New pattern long-life conversion ion current tester with fast response and high sensitivity Oxygen Nitrogen Analyzer.
- N2 or O2 concentration display.
- Checking the sensor working state automatically and unique double-line working change mode extending the sensor's life.
- Setting alarm value freely.
- High precision, automatic temperature compensation, eliminating the impact of environmental temperature Oxygen Nitrogen Analyzer.
Technical Specification
| Monitor | Five-digital dynamic LED monitor, visible display window: 90mm×25mm |
| Measure Range | 10.00~96.00% O2 |
| Measure Mode | Air in-flowing or convection diffusing |
| Sample Gas Flow | 150~300ml/mim |
| Accuracy | ±2% F.S |
| Response Time | 90% of FS reading ≤20 seconds |
| Ambient Temp | -10ºC~+50ºC |
| Ambient Humidity | <80%RH |
| Stability | <±1%.FS (168h) |
| Signal Output | 4~20mA |
| Power Supply | 220±10% VAC, 50/60Hz, the power loss ≤6VA |
| Sensor Life | 20000 hours at 25ºC and 1 atm |
| Warranty | 12 months analyzer; 12 months sensor |
| Weight | 1kg |
| Appearance Dimension | 160mm×80mm×176mm (W×H×D) |
| Opening Size | 151mm×75mm |
