• Model NO.：HT-LA458
• Type：Zirconia
• Test Principle：Zirconia
• Transport Package：Cartoon Box
• Specification：235*400*422(mm)
• Trademark：HT
• Origin：China
• HS Code：9027100090
• Production Capacity：200 Pieces, Month

Basic Info.

Model NO. HT-LA458 Type Zirconia Test Principle Zirconia Transport Package Cartoon Box Specification 235*400*422(mm) Trademark HT Origin China HS Code 9027100090 Production Capacity 200 Pieces/ Month

Product Description

Technical Specifications:

   Measurement Principle: Zirconia
   Display Mode: 7-inch serial port capacitive screen
   Measurement Range: 0~10/100/1000PPm/1.00%/25.00% O₂
   Measurement Accuracy: 0~1000PPm/1.00%/25.00%≤±1%FS
                                           0~100PPm≤±2%FS
                                           0~10PPm≤±5%FS
   Resolution: 0.1PPm (trace)
                      0.01% (normal)
   Repeatability: ≤±1.0%FS
   Response Time: T₉₀≤30S
   Output Port: 8-channel 4-20mA.DC (Non-isolated output, load resistance< 1KΩ)
                        8-channel 0-10V.DC (Non-isolated output, load resistance> 10KΩ)
                        8-channel programmable alarm output (Dry contact type), maximum load AC220V/2A
   Communication Mode: RS232 (default) or RS485
   Power Supply: AC100~240V 50/60Hz, power dissipation<200VA
   Environment Temperature: -10ºC~+50ºC
   Storage Environment Humidity: <90%RH, non-condensing
   Operation Environment Humidity: <100%RH, non-condensing
   Sample Gas Temperature: 0ºC~60ºC
   Sampling Mode: Extraction sampling
   Sample Gas Flow: 400~600mL/min
   Gas Inlet Pressure: -10kPa≤ relative pressure≤5kPa (when pressure <5kPa, please indicate specific negative pressure value when ordering)
   Gas Outlet Pressure: Free venting (under safe conditions)
   Background Gas: N₂ or other inert gas
   External Size: 235mm×400mm×422mm (H×W×D)
   Hole-Cutting Size: 237mm×361mm (H×W) , embedded mounting
   Sensor Service Life: >5 years (under normal conditions of use)
   Gas Circuit Port: NPT 1/8 internal thread
   Instrument Weight: Net weight 15.8Kg
   Installation Method: Embedded mounting / counter mounting

Features:
   a.   Friendly communication menu allows an intuitive and convenient operation;
   b.   7-inch serial port capacitive screen display is clear and easy to see;
   c.   The original imported zirconia sensor consumes no service life when power is off, and is has a high measurement accuracy, rapid response speed and small zero drift value;
   d.   With the gas circuit blockage alarm and self-protection function, the instrument could turn off the sampling pump automatically when the gas circuit malfunctions, which could extend the service life of sampling pump and sensor;
   e.   8 channels can operate independently at the same time without interfering each other;
   f.    40 thousand pieces of historical data can be stored, and they can be read locally in list or exported through USB disk;
   g.   The instrument allows multi-point fractional liner calibration, satisfying the need for an accurate measurement of oxygen content among the full range;
   h.   The response speed is rapid and it could measure 0.1 PPm at minimum;
   i.    Automatic temperature and pressure compensation could eliminate the impact of environment temperature and pressure changes on the measured value;
   j.    Original imported sampling pump is built in and has a long service life and stable performance;
   k.   Embedded mounting is easy and convenient to install and maintain;
   l.    RS232/RS485 communication port is determined through dial switches at the rear panel, and user could set it freely.

Application:
   It is widely applied in the online oxygen measurement in protection gas of wave soldering, reflow soldering, soldering oven in electric or semi-conductor industry and inert gas sintering furnace, etc.

Order Notice (Please indicate following messages when placing orders)
   Measurement range
   Measured gas pressure
   Background gas composition
