• Model NO.：SV-5Q
• Certification：CE, RoHS, TUV, BV
• Gas：CO2
• Type：Electrochemical Gas Analyzer
• Preheating Time：10min
• Weight：10kg
• Barometric Pressure：70.0~106kpa
• Power Supply：AC220V 50Hz
• Warm up Time：10minutes
• Rotate Speed：0~10000rpm
• Oil Temperature：0-120degree Centigrade
• Volume：460 * 315 * 225mm
• Transport Package：as Required
• Trademark：chinacoal
• Origin：Shandong, China
• HS Code：8501109901
• Production Capacity：50, 000 PCS,Year.

exhaust gas analyzer

measuring range

CO:0~10.0 10^-2(%) CO₂:0~20.0 10^-2(%) HC:0~10000 10^-6(ppm) O₂:0~25.0 10^-2(%) NO:0~5000 10^-6(ppm)

Choose: oil temperature:18ºC~150ºC speed:100~20000rpm

Repeatability error

≤±2%

Zero drift

CO:±0.06 10^-2(%)/4h CO₂:±0.5 10^-2(%)/4h HC:±30 10^-6(ppm)/4h

O₂:±0.1 10^-2(%)/4h NO:±25 10^-6(ppm)/4h

Distance drift

No more than the permissible error value(4 hours)

Indication error

CO:±5%(absolute error,±0.06 10-2 )

CO₂:±5%(absolute error,±0.5 10^-2)

HC:±5%(absolute error,±12 10-6   )±5%(absolute error,4001~10000ppm)

O₂:±5%(absolute error,±0.1 10^-2)    NO:±4%(absolute error,±25 10^-6)

environment condition

oil temperature:±2ºC(relative error) speed:±1.0%(relative error) temperature:0ºC~40ºC humidity:≤80% atmospheric pressure:60~105KPa

Power Supply:AC 220V±10%;50Hz±1Hz

Preheating time

10min

Weight

10Kg

Volume

460 * 315 * 225mm

Sampling method

tail gas : Direct sampling,Sampling tube length 5m,Sampling probe length 900mm;

oil temperature:The temperature measuring head is inserted into the bore of

the engine oil gauge,insert lengthsame with length,block the plug by rubber,in case of oil spray,conductor length:5m;

speed:Put the speed clamp on tachometer on a high tension cord of a gasoline
