• Model NO.：HT-LG210
• Type：Infrared Absorption Analyzer
• Test Principle：Infrared
• Transport Package：Cartoon Box
• Specification：176*483*355(mm)
• Trademark：HT
• Origin：China
• HS Code：9027100090
• Production Capacity：200 Pieces, Month

Basic Info.

Model NO. HT-LG210 Type Infrared Absorption Analyzer Test Principle Infrared Transport Package Cartoon Box Specification 176*483*355(mm) Trademark HT Origin China HS Code 9027100090 Production Capacity 200 Pieces/ Month

Product Description

Technical Specifications:
   Measurement Principle: Infrared principle
   Display Mode: 320×240 dot matrix color LCD
   Measurement Range: 0~10/40PPm,0~2000/5000PPm CO₂
   Measurement Accuracy: ≤±2.0%FS (sensor with higher accuracy available)
   Resolution: 0.1PPm
   Repeatability: ≤±1.0%FS
   Response Time: T₉₀≤30S
   Warm-Up Time: Maximum 300s
   Output Port: 4-20mA (Non-isolated output, load resistance<1KΩ)
                       0-10V.DC (Non-isolated output, load resistance>10KΩ)
                       2 ways of programmable alarm output (Dry contact type, maximum load 220V/2A)
                       1 way of error alarm output
   Communication Mode: RS232 (default) or RS485
   Power Supply: AC88~264V 50/60Hz, power dissipation <150VA
   Environment Temperature: -10ºC~+50ºC
   Storage Environment Humidity: <90%RH, non-condensing
   Operation Environment Humidity: <100%RH, non-condensing
   Sample Gas Temperature: 5ºC~45ºC
   Sampling Mode: Gas in
   Sample Gas Flow: 400~600mL/min
   Gas Inlet Pressure: 5Kpa≤ relative pressure≤200Kpa (relief valve is recommended if the pressure >200Kpa)
   Gas Outlet Pressure: Free venting (under safe conditions)
   Size: 176mm×483mm×355mm (H×W×D)
   Hole-Cutting Size: 169mm×442mm (H×W) (embedded mounting)
   Sensor Service Life: >5 years (under normal conditions of use)
   Gas Circuit Port: NPT 1/8 internal thread
   Instrument Weight: Net weight 10.5Kg
   Installation Method: Embedded mounting / counter mounting

Features:
   a.   Friendly communication menu allows an intuitive and convenient operation;
   b.   320×240 graphic dot-matrix color LCD display is clear to see;
   c.   The original imported infrared sensor has a high measurement accuracy, stable performance, long calibration cycle, etc.;
   d.   The analyzer is based on infrared absorption principle, therefore no wear will be made to the measurement part and the analyzer needs no maintenance, and it is also of good selectivity to measured gas;
   e.   Automatic temperature and pressure compensation could eliminate the impact of environment temperature and pressure changes on the measurement accuracy
   f.    40 thousand pieces of historical data can be stored automatically, enabling user to read historical data freely;
   g.   The instrument allows multi-point fractional liner calibration, satisfying the need for an accurate measurement of oxygen content among the full range;
   h.   The power is supplied in a wide range and could reduce impact from public electricity fluctuation;
   i.    RS232 (default) or RS485 digital communication port can be selected according to clients' requirement, to realize unidirectional or bidirectional communication with computer or other digital communication facilities.

Application:
   It is special for air separation.

Order Notice (Please indicate following messages when placing orders)
   Measurement range
   Measured gas pressure
   Background gas composition
