• Model NO.：BK-LCG1100
• Certification：ISO
• Spectrometer Detector：SDD
• Stationary Phase：Solid Adsorbent
• Mobile Phase：Liquid
• Chromatography Type：Liquid Chromatography
• Chromatographic Column Type：Convetional Analytical Column
• Chromatographic Column Length：10~30cm
• Chromatographic Column Diameter：20~40mm
• Product Name：Liquid Chromatography
• Wavelength Range：190-800nm
• Wavelength Repeatability：≤0.1nm
• Wavelength Accuracy：≤±1.0nm
• Band Width：6nm
• Response Time：0.0s-5s
• Baseline Noise：0.25X10-5au
• Power Supply：AC110,220V±10%, 50,60Hz
• Transport Package：Export Packing
• Specification：BK-LCG1100
• Trademark：BIOBASE
• Origin：China
• Production Capacity：500 PCS , Mout

Product Parameters

Model

BK-LCI1100

BK-LCG1100

High Pressure Constant Flow Pump

Double plunger reciprocating pump

1 set

2 set

Flow Range

0.001mL/min-10.000mL/min

Setting Step Size

0.001mL/min

Flow Accuracy

≤±0.3% (1.00ml/min, H2O,R.T.,8.5MPa)

Flow stability

RSD≤0.1% (1.00ml/min, H2O,R.T.,8.5MPa)

Maximum Pressure

42MPa

Display Pressure Error

≤±3.0%

Pressure Fluctuation

≤1.0%

Power Dissipation

80W

UV/VIS

Detector

Wavelength Range

190-700nm

Wavelength Repeatability

±0.1nm

Wavelength Accuracy

≤±1.0nm

Spectrum Band Width

8nm

Response Time

0.0s-4.9s

Linearity Range

1.8AU (5%)

Baseline Noise

≤±1×10-5AU

Baseline Drife

≤2.0×10-4AU/h

minimum Detectable Concentration

4.0×10-9g/mL(Naphthalene in Methanol Solution)

Detector Cell

Optical Path--10mm, Volume--10μL

Light Source

Deuterium Lamp

Power Dissipation

100W

Gradient Mixer

/

GM1100

Sampler Injector

1

Supersil ODS2 5μm ID4.6×200mm

1

Workstation (Without Computer & Printer)

1

Valve Mounting Frame

1

Kits

Isocratic System Kits

Gradient System Kits

Power Supply

AC110/220V±10%, 50/60Hz

Optional Accessory

Column Oven
