• Model NO.：K1100,K1100F
• Weight：0-100Kg
• Power Source：AC220V±22V
• Customized：Non-Customized
• Measuring Range：0.1mg N - 200mg N
• Analysis Time：5 - 10 Min,Sample
• Burette Volume：1.0 μl, Step
• Transport Package：Export Package
• Specification：455*391*730mm
• Trademark：ZSIMC
• Origin：China
• HS Code：9027809900
• Production Capacity：1000 Sets,Year

Basic Info.

Model NO. K1100/K1100F Weight 0-100Kg Power Source AC220V±22V Customized Non-Customized Measuring Range 0.1mg N - 200mg N Analysis Time 5 - 10 Min/Sample Burette Volume 1.0 μl/ Step Transport Package Export Package Specification 455*391*730mm Trademark ZSIMC Origin China HS Code 9027809900 Production Capacity 1000 Sets/Year

Product Description

K1100/K1100F Automatic Kjeldahl Analyzer
 K1100/K1100F Automatic Kjeldahl Analyzer is an automatic device integrating distillation and titration functions designed based on classic Kjeldahl nitrogen determination method. It's equipped with the latest core control system, powerful automation and high-quality components, can easily achieve automatic waste discharge and cleaning of digestion tubes and titration cups, control steam supply and have real-time detection of condensation temperature. High-accuracy charging pump and titration system ensure test results accuracy, and multiple fluid level detection gives smooth test process. Characteristics

1. Automatic waste discharge and cleaning ensure operator safety and save work time.
2. External titration cup design gives operator real-time control of the whole test process.
3. Steam flow is controllable, satisfying different test requirements.
4. Regent barrel enjoys fluid absence warning function, ensuring smooth test going.
5. High-precision charging pump and titration ensure test results accuracy.
6. USB or RS485 interface is optional for PC connection.
7. The temperature of distilled liquid is detected real time. If the temperature of distilled liquid is abnormal, to ensure the accuracy of experiment's result, instrument will stop working.
8. Double distillation model is used for meeting different experiments, to retard the speed of acid-base reaction.
9. Digestion tube fast drain function is used to avoid operator touch distilled hot reagents, protecting operators.

 Automatic completion of distillation, titration, calculation, printing, waste discharge and Multiple protections i.e. failure self-detection, hints of condensed water shortage, displacement of safety door and nitrogen tube, and so on.
Large LCD touch screen gives visual operation and abundant information, enabling user to have a good command of it.

K1100F
Complete compatible design
Compatible with congeneric products perfectly

Performance advantage

1. Using φ42 digestion tube
2. Titration while Distillation, enhance the efficiency rapidly.
3. User friendly design, color touch screen, easy for operating
4. Faster ARM system, faster operating rate

( Digestor Model SH220F and SH420F is matching K1100F, with φ42 digestion tube)
  Technical Data

Measuring Range	0.1mg - 200mg N
Analysis Time	5 - 10 min
Reproducibility	Average value relative error 0.5%
Recovery	≥ 99.5%
Burette volume	1.0 μL/ step
Sample capacity	Solid ≤5g/sample; Liquid ≤ 20mL/sample
Water Consumption in distillation	1.5L/m
Data storage capacity	K1100: 1000sets;   K1100F: 1800sets
Power Supply	220 AVC ±10%; 50Hz
Power	2Kw
Net Weight	38Kg
Dimension	455*391*730mm
