• Model NO.：NFT
• Combustion Gas：95% Butane Gas or Propane Gas
• Burner Flame Angle：0- 45 °
• The Flame Height：Less Than 200ms
• Test Space：≥0.5m3
• Delivery Time：40 Days
• Test Object：Electrical Equipment
• Color：White
• Language：English
• OEM Service：Available
• Transport Package：Plywood Case
• Specification：Stainless steel
• Trademark：AI
• Origin：China
• HS Code：9031809090
• Production Capacity：20 Sets,Month

1Needle burnerIt is made of stainless steel:the hole dia. 0.5mm ± 0.1mm, diameter≤0.9mm, length≥35mm2Burner flame angle0- 45 ° (arbitrary adjustment)3The combustion gases95% butane gas or propane gas4Subplatewhite pine plank ( 10mm),
Surface covered by standard silk paper
200mm ± 5mm below the flame5Temperature range0--1000 ºC6The flame temperature requirements100 ± 2 ºC ~ 700 ºC ± 3 ºC,
Heating rise time: 23.5 ± 1.0s;7The flame height12mm ± 1mm8Ignition time0s ~ 999.9s adjustable, generally 30s9Burning time0s ~ 999.9s, automatic recording, manual pause10Test Space≥0.5m3, black background, (can be customized cubic 0.75 m3 or 1 m3 according to customer requirements)11Temperature sensorK-type insulation-sheathed thermocouple (Φ0.5mm)12DimensionsL1120 * W520 * H1250mm13The diameter of exhaustΦ100mm14Power supply220V / AC, 50Hz

Factory overview

Customer Feedback

Germany

USA

Transporation

FAQ
1.What's the delivery time?
About 40 working days.

2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.

3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.

4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every person.
